| Item | Capability | Max Capability |
| Layers | 1-30 Layers | 4-10 Layers |
| board thickness | 0.2-6.4mm | 0.32-6.4mm |
| HDI TYPE | 1+N+1/2+N+2/3+N+3 | 1+N+1/2+N+2/3+N+3 |
| Min laser drilling bit | 110μm | 80μm |
| laser dnlling capability | CO2 laser dnlling | CO2 laser dnlling |
| matenal | FR4/FR4 Halogen free | FR4/ Taconic/ Rogers/ others on request |
| TG | 135/150/170 | 140/150/170/190 |
| PP TYPE | 106/1080/2116/1506/7628 | 106/1037/1080/2116/1506/7628/1078/2113 |
| COPPER | 12μm/18μm/35 μm/70μm/350μm | 9μm/12μm / 18μm/ 35 μm/70 μm/105 μm/350μm |
| Copper into holes thickness | 20 μm(25 μm) | 13μm/20μm/25μm |
| Min width &space | 75 μm/75 μm | 50μm/50μm |
| sodlermask aglight | (+/-) 38μm | (+/-) 25μm |
| Min green soldermask bndge | 60μm | 50μm |
| soldermask | Green /white / black/ red/ blue | Greer/ white /black /red /blue |
| panel drawing | Min5mm*5mm Max 1200*500mm | Min5mm*5mm Max1200*500mm |
| production panel size | 620mm*543mm | 620mm*543mm |
| Min amdar ring | 125μm | 76μm |
| Mindrilling bit | 0.2mm | 0.1mm |
| Min routing bit | 0.8mm | 0.6mm |
| Surface | OSP/HASL LEAD FREE/lmmersion Tir/ ENIG/Plated NI/AU/ lmmersion Ag | OSP/ HASL LEAD FREE/ lmmersionTin/ ENIG/ Plated NI/AU/ lmmersion Ag |
